Brass A1 / A2 Cable Gland
A1 / A2 Cable Gland Manufacturer & Supplier from India
Jamnagar Metal Industries offers a wide range of A1 / A2 Cable Glands designed with an outer displacement seal, specifically developed for use with unarmoured cables having a rubber outer sheath. These cable glands are suitable for both indoor and outdoor applications, providing reliable sealing, strain relief, and long-term performance.
A1 / A2 cable glands are widely used in electrical panels, control equipment, machinery, and industrial installations where protection of the cable outer sheath is essential.
Product Overview – A1 / A2 Cable Glands
A1 / A2 Cable Glands are engineered to secure the outer sheath of unarmoured cables using a displacement sealing concept. This design ensures effective protection against dust, moisture, and environmental influences, making the glands suitable for varied operating conditions.
Manufactured in compliance with BS EN 62444 : 2013, these glands deliver consistent quality, dimensional accuracy, and dependable sealing performance
Applications
Unarmoured cables with rubber outer sheath
Indoor electrical installations
Outdoor electrical enclosures
Control panels and switchgear
Industrial machinery and equipment
Design Features
Compliant with BS EN 62444 : 2013
Outer displacement seal design
Suitable for indoor and outdoor use
Secure grip on cable outer sheath
Easy installation and maintenance
Reliable strain relief
Technical Data – A1 / A2 Cable Gland
| Parameter | Specification |
|---|---|
| Product Type | A1 / A2 Cable Gland |
| Cable Type | Unarmoured cables with rubber outer sheath |
| Sealing Method | Outer displacement seal |
| Application | Indoor and outdoor use |
| Design Standard | BS EN 62444 : 2013 |
| Material | Brass |
| Surface Finish | Nickel Plated (standard) |
| Thread Type | ISO Metric |
| Protection | Dust and moisture resistant |
| Operating Temperature | Suitable for standard industrial environments |
| Installation | Lock nut fixing |
| Strain Relief | Yes |
| Accessories | Lock Nut (standard) |
| Compliance | BS EN 62444 : 2013 |
| Customization | Sizes and finishes available on request |
Cable Gland Selection Table
(All dimensions except thread sizes are in millimeters)Note: Special or customized requirements are accepted.
| NAME | ENRTY THERAD | CABLE ACCEPTANCE DETAILS | ACROSS FLAT | ACROSS CORNER | |
|---|---|---|---|---|---|
| DIA. C | LENGTH MINIMUM E | DIA MAX. A | |||
| A2-16L | 16 | 10 | 3.5-9 | 21 | 24 |
| A2-20S | 20 | 15 | 8-12 | 22 | 25 |
| A2-20L | 20 | 15 | 11-14 | 24 | 27 |
| A2-25S | 25 | 15 | 12-17 | 27 | 30 |
| A2-25L | 25 | 15 | 13-20 | 30 | 33 |
| A2-32S | 32 | 15 | 16-23 | 40 | 44 |
| A2-32L | 32 | 15 | 19-26 | 40 | 44 |
| A2-40S | 40 | 15 | 23-29 | 50 | 55 |
| A2-40L | 40 | 15 | 25-33 | 50 | 55 |
| A2-50S | 50 | 15 | 31-38 | 55 | 61 |
| A2-50L | 50 | 15 | 36-44 | 59 | 65 |
| A2-63S | 63 | 15 | 42-50 | 66 | 72 |
| A2-63L | 63 | 15 | 48-56 | 72 | 78 |
| A2-75S | 75 | 15 | 54-62 | 80 | 87 |
| A2-75L | 75 | 15 | 60-68 | 83 | 93 |
| A2-90L | 90 | 15 | 66-77 | 103 | 114 |
Dimensions are subject to change without prior notice.
Advantages of A1 / A2 Cable Glands
Strong sealing on cable outer sheath
Suitable for non-armoured cable applications
Reliable performance in indoor and outdoor conditions
Manufactured to international standards
Wide size range for various cable diameters
Cost-effective and durable solution
Why Choose Jamnagar Metal Industries?
Experienced manufacturer of cable glands and brass components
Compliance with international quality standards
Precision manufacturing and consistent quality
Bulk supply capability for projects and exports
Customization support for special requirements
